DEGERtracker S60H/S70

Specs

DEGERtracker S60H ‐ up to 26 standard modules (60 cells), 21 standard modules (72 cells)

DEGERtracker S70 ‐ up to 30 standard modules (60 cells), 24 standard modules (72 cells)
MLD technology (Maximum Light Detection) – sensor based “intelligent” control
Wind Load: DEGERtracker S60H up to 170 km/h, 1,35 kN/m2





CONTACT US TODAY

DEGERtracker S70 up to 130 km/h, 0,85 kN/m2
Rotating angle East‐West : +/‐ 45°
Max. slope in N/S direction: 1.5% , max. slope in E/W direction : 10% when using concrete foundations (can be extended when using higher foundations)
Energy Converter 6 (EK6) with wind guard
Wire tray: All cables are rooted at the middle pole of the tracker
Earthing of structure: Standard earthing at one pole
Power Supply 100 … 240VAC, Power consumption: 1W in control mode 1W, 15W with active, power consumption/year 15 kWh (approx.)

Download Specifications
