• High performance SMD design
• Efficacy up to 150lm/W
• Electrical: 100-277V~, 50-60Hz, PF≥0.95
• LED life projection >100,000 hours (TM21 L70)
• Energy savings up to 90%, (depending on
installation and usage patterns)
• CCT: 5000K (other 0K available to special order)
• CRI>70 (CRI>80 optional)
• Standard Beam angle 120 (50 and 90 Optional)
• Superior uniformity
• Superior temperature stability
• Temperature tested for the toughest conditions
• Quality Meanwell long life driver
• Compact size (383mm x 195mm)
• Light weight (6-7kg)
• Tempered safety glass diffuser
• Operating range -30~+50 C
• Body : Aluminium alloy
• Stainless steel screws
• IP65 Protection rating
• 0.3m flex (other lengths and plugs optional)
• Five years warranty
HiCloud Specifications Download
CONTACT US TODAYHiCloud is an innovation in LED high bay lighting. Thinking
outside the square, OK LED designers have rejected COB for
a smarter SMD design providing a smaller, lighter, and more
powerful solution.
A long maintenance free life is a vital value of LED, and heat
management governs LED life. HiCloud’s superior temperature
management, supported by the use of under driven, high
specification components means HiCloud is perfect for even
the toughest conditions.
